BC3000+D Diesel Fuel Injection Pump Test Bench diesel injection pump calibration machine

BC3000+D Diesel Fuel Injection Pump Test Bench| diesel injection pump calibration machine fro testing the euro ii mechanical pumps

0086-18253885135

info@beacon-machine.com


Make an inquiry

BC3000+D diesel fuel injection pump test bench is a kind of fuel injection pump test bench adopt industrial pc with color CRT, It's the newly researched production for the direction of high power and safety to the environment.

1. Measurement of each cylinder delivery at any speed
2. Test point and interval angle of oil supply of injection pump.
3. Checking and adjust the mechanical governor.
4. Checking and adjusting the distributor pump.
5. .Experiment and adjusting of behavior of supercharging and compensatory device.
6. Measurement of oil return of distributing pump
7. Testing of the electromagnetic valve of distributor pump.(12V/24V)
8. Measurement of the internal pressure of distributor pump.
9. Checking of the advance angle of advance device.(on request)
10. Checking the sealing of injection pump body
11. Install tube of auto-sucking oil supply can check on oil supply pump(including VE pump.)
12. Checking the travel of stroke
13.oil lubricate(on request)
14.Cast iron base(on request)
15. Foced cooller(on request)





Adjustable cylinders numbers:12

Out power(Kw):5.5,7.5, 11,15,18.5

RPM:0-4000
