Main function
1.Measurement of each cylinder delivery at any speed.

2. Test point and interval angle of oil supply of injection pump.

3. Checking and adjust the mechanical governor.

4. Checking and adjusting the distributor pump.

5. .Experiment and adjusting of behavior of supercharging and compensatory device.

6. Measurement of oil return of distributing pump

7. Testing of the electromagnetic valve of distributor pump.(12V/24V)

8. Measurement of the internal pressure of distributor pump.

9. Checking of the advance angle of advance device.(on request)

10. Checking the sealing of injection pump body

11. Install tube of auto-sucking oil supply can check on oil supply pump(including VE pump.)

(1) Test Bosch, Delphi, Denso, Siemens, Caterpillar, Cummins, solenoid or piezo common rail injector and pump.

(2) Injector coding can be generated, including Bosch IQA / IMA / ISA, Denso 16/22/24/26/28/30/32QR, Delphi I2C / I3C, Siemens IIC and Cummins XPI(optional);

(3) Can test Bosch, Caterpillar, Cummins, Delphi EUI and EUP, including Delphi E3 double solenoid EUI and Cummins M11 double pulsing EUI  (optional);

(4) Test HEUI injector and HEU pump (optional);

(5) Test Caterpillar 320D pump (optional);

(6) Test VP37,VP44,RED4,Denso V3/V4/V5 pump (optional);

(7) Test Cummins HPI injector,PT pump (optiona);

(8) Test Injector response time,EUI/EUP BIP；

(9) Test injector resistance and indctance.

(10) Test the armature lift of the injector solenoid valve (AHE).

(11) The test plan is consistent with the original data, and the test accuracy reaches the original factory standard;

(12) The database is fully open, the part number can be increased.

(13) Automatic network upgrade, test data and functions are kept up to date;
