CRI325 High Pressure Common Rail Diesel Injector Tester Piezo Injector Test Bench

CRI325 full- featured high- pressure common rail injector tester,support the driving of common rail coil and piezo injectors such as BOSCH, DENSO,DELPHI, CAT, etc., and can drive two channels at the same time. The screen is a high-definition 4-inch LCD,and the same screen can display more parameters.

0086-18253885135

info@beacon-machine.com


Make an inquiry

CRI325 is a dual-channel, full-featured high-pressure common rail injector tester.

1.Supports the driving of common coil and piezo injectors such as BOSCH, DENSO, DELPHI, CAT, etc., and can drive two channels at the same time. The screen is a high-definition 4-inch LCD , and the same screen can display more parameters.

2.Supports multiple working modes such as injector drive, CRIN4 injector drive, AHE drive, insulation test, Siemens valve air gap measurement, etc. It can measure the resistance and inductance of coil injectors, and it can measure the resistance and capacitance of piezo injectors.


Function

CRI325

Coil injector driver

Piezoe injector driver

Resistance measurement

Inductance measurement

Capacitance measurement

AHE measurement

Insulation measurement

Siemens air gap measurement

Drive parameter adjustment

Multiple working conditions settings

Counting oil switch

Dual valve actuation
