EPS211 HIGH PRESSURE COMMON RAIL INJECTOR TEST BENCH

1.INTRODUCTION

2.FUNCTION

3.TECHNICAL PARAMETER

1.INTRODUCTION

The EPS211 high-pressure common rail test bench imitates diesel engine ECU (Engine Control Unit), and provides common rail system control signals (CP1/ CP2/ CP3/ HP3/ HP4/ DELPHI), such as Bosch, Denso, Delphi, and Siemens, to drive high-pressure common rail. The oil pump and the high-pressure common rail injector are working, and the driving signal parameters can be set by the user according to their actual conditions, and can be grouped and saved, which is convenient for maintenance personnel to judge and repair the working state of the high-pressure common rail system.

The power of the EPS211 high-pressure common rail test bench is 2.6KW.

2.FUNCTION

(1) Test the sealing performance of the common rail injector

(2) Test the full load performance of the common rail injector

(3) Test the mid-load performance of common rail injectors

(4) Test the idling performance of the common rail injector

(5) Test the pre-injection performance of the common rail injector

3.TECHNICAL PARAMETER

(1) Measuring motor speed: 0～3000rpm; oil pump speed: 0--1500rpm

(2) Working pressure: 0-200Mpa

(3) Fuel tank volume: 10L;

(4) Test oil filtering accuracy: 3μ;
