Diesel Injector Testing Machine with EUI EUP HEUI Function CR819S Common Rail Injector and Pump Test Bench

CR819S Common Rail Injector and Pump Test Bench is to imitate the working condition of diesel engine ECU (engine control unit), At the same time, it provides control signals for common rail systems such as Bosch and DELPHI. Drive the high pressure common rail oil pump and the high pressure common rail injector to work; The driving signal parameters can be set by users according to their actual situation, And save it，It is convenient for maintenance personnel to judge and maintain the working state of the high-pressure common rail system.

Standard function:
1. Common injector test
2. Piezo injector test
3. common rail pump test
4. Denso Hpo Pump Test
5. Bosch ，denso, siemens, Delphi coding functions
Optional function:
1. Test 2/4/6 injectors in same times
2. Test 2/4/6 injectors in same times
3. Test HEUI CAT C7 C9 3126B
4. CAT 320D pump test system with test kits
5. CAT C7 C9 pump test system with test kits
6. BIP test system with test kits
7. CP4 pump test system with test kits and diesel supply booster pump
8. Cummins PT injector test system with test kits
9. Cummins PT pump test system with test kits
10. Cummins HPI Q60 X15 injector test system with test kits

TECHNICAL PARAMETERS

1.Main motor speed:	0-4000 r / min can be adjustable
2.Motor power:	11KW/15KW/18.5KW/22KW optional
3.Fuel Injector open	12V, 80V, 150V Control accuracy:
4.Voltage Control range:	phase adjustment
5.Injector opening	0-1000HZ Control accuracy: 1HZ
6.Frequency Control:	0-65535us
7.Fuel injector hold time control:	0-1000 times
8.Delivery oil count control accuracy:	1 times
9.Fuel pressure control	0-2400bar
10.Control accuracy:	1bar
11.Electronic power:	380V /220V three phase ; 220V single phase
12.Product size:	178115156
13.Weight:	906kg(including cam box);690kg(excluding cam box)
