    Beacon Machine HEUI Injector Test Bench

    Beacon Machine HEUI Test Bench is designed to test up to four HEUI injectors, which are equipped on the engines

    0086-18253885135

    info@beacon-machine.com


    Make an inquiry

    Improve fuel economy & enhance performance

    Measurement fuel delivery of four HEUI injectors
    Sealing test for injectors upper seat of the solenoid control valve
    It can test HEUI(CAT C7/C9,CAT 3408...)
    Main parameter
    Output power:3KW
    High pressure adjust range:0-500bar set freely .
    Low pressure adjust range:0-6bar
    Electronic fuel delivery system,computer display .



    Function

      · Sealing test for injector upper seat of the solenoid control valve
    Specification
    · AC Power: 3–Phase, 380V/50Hz or 230V/60Hz or 460V/60Hz
    · Drive System for Actuation Pump
    7.5kW AC Induction Motor
    · VFD(Variable Frequency Drive) Motor Controller
    · Actuation Pump
    · Pressure Range of Actuation Oil: 0~3000psi (0~210bar)
    · Low Pressure Test Oil Supply:0~60psi (0~4bar)
    · Test Oil Tank Capacity:10.5US gallons (40 liters)
    · Test Oil Temperature Control
    · Range: 30~50°C
    · Accuracy: +/- 1°C
    · Digital Display
    · Test Oil
    · The HUS-1001 is designed to run on single test oil for both oil injection and high pressure actuation to HEUI injectors.
    · The test oil should meet ISO4113 standard.
    · Injection Quantity Measurement:Two Groups of 4 Graduates, 45/150cc
    · Full Functioned HEUI Control Module
    · Test Oil Filtration: 5µm, Full Flow

     Appliciation



    Test bench is designed to test up to four HEUI injectors, which are equipped on the following engines:

    · Navistar T444E, as Ford 7.3L PowerStroke Engines
    · Navistar DT466E
    · Navistar I530E
    · Caterpillar 3126B
    Adapting Kits for Testing One Ford 6.0L PowerStroke Engine HEUI Injector
    · Adapting Kits for Testing One CAT C7/C9 HEUI Injector
    · Adapting Kits for Testing One CAT 3408 HEUI Injector
