YYQ-100 Turbine drive shaft dynamic balancing machine

YYQ100 dynamic balancing machine is a horizontal dynamic balancing machine,


Make an inquiry

Brief Introduce

YYQ100 dynamic balancing machine is a horizontal dynamic balancing machine,

using roller bearings, ring belt drive, computer measurement, color screen

display and realtime imbalance value and angle of rotation speed, widely used in motors,

fans, diesel engines, automotive and other industries can be single sided, both sides

and a number of correction to balance the surface measurements.

Model

YYQ-100

YYQ-200

YYQ-300

YYQ-500

YYQ-1000

Mass of workpiece:kg

1-100

2-200

5-300

10-500

10-1000

Max.diameter of workpiece:mm

Φ900

Φ1000

Φ1200

Φ1600

Φ1600

Distance between two supporting

mm

800-1100

100-1100

150-1500

150-1500

150-2600

Shaft diameter range:

mm

Φ10-90

Φ10-90

Φ20-90

Φ20-130

Φ20-130





Φ90-180Optional

Φ90-180Optional

Φ120-240Optional

Φ120-240Optional

Diameter range at the lap belt drag:mm

Φ30-300

Φ30-300

Φ30-450

Φ40-500

Φ40-650

Balancing  speed:

r/min

300-2500

300-2500

300-2500

300-2500

180-2500

Min. achievable residual unbalance:

gmm/kg

≤0.5

≤0.5

≤0.5

≤0.5

≤0.5

unbalance reduction ratio:

%

≥90

≥90

≥90

≥90

≥90

Driver power:

KW

1.5

1.5

4.0

4.0

5.5

speed adjustment mode:

Frequency

Frequency

Frequency

Frequency

Frequency
